Gentex CR 120VAC Carbon Monoxide Alarm with Relay

The Gentex CR is a 120VAC carbon monoxide alarm with 9V battery backup and built-in relay outputs for remote annunciation or auxiliary control. It combines electrochemical CO sensing, an 85 dBA sounder, tandem interconnect capability, alarm memory, and wall or ceiling mounting for residential and dwelling unit applications. Key Specifications: Type: 120VAC carbon monoxide alarm with relay Core Function(s): Provides electrochemical carbon monoxide detection with local audible alarm and auxiliary relay output Power: 120VAC, 60 Hz with 9V alkaline battery backup Indicators/UI: Green LED for AC power, red LED status indication, push button test, and 8-hour alarm memory Sensing: Electrochemical carbon monoxide sensing Alarm Output: 85 dBA piezo horn with temporal 4 pattern Relay Output: One Form A and one Form C relay Relay Rating: 1.0 A at 30VDC max; 0.3 A at 125VAC max Mounting: Wall or ceiling mount to standard electrical junction boxes Operating Range: 40 to 100 F Backup Battery: 9V alkaline battery End-of-Life: 10-year end-of-life timer and indication Interconnect: Tandem interconnect with compatible Gentex tandem-capable alarms Alternate Part Numbers: PN # 918-0036-002 System Compatibility: Compatible with Gentex tandem-capable alarms in the S/C/SC/H series
