Wheelock ELSPKWC-N Eluxa Ceiling Speaker

The Wheelock ELSPKWC-N is a low-profile high fidelity ceiling speaker for indoor fire alarm, voice evacuation, and emergency communications systems. It is a white Eluxa series speaker with no lettering, field-selectable 25 or 70 VRMS input, and selectable power taps from 1/8 watt to 2 watts, with 5 watts available on 70V systems. Key Specifications: Type: Indoor ceiling speaker Core Function(s): Provides high intelligibility voice messages and tone signaling for fire alarm and emergency communications Power: 25/70 VRMS input; selectable taps from 1/8 watt to 2 watts, or 5 watts on 70V Indicators/UI: Built-in tap selection switches under snap-on grille cover Frequency Range: 300 to 8000 Hz Sound Output: Up to 87 dBA at 10 feet Mounting: Ceiling mount with included mounting plate; fits 4-inch square, 2-1/8-inch deep backbox or dedicated ceiling backbox Wire Range: #12 to #18 AWG Operating Range: 32 F to 122 F; up to 93 percent non-condensing humidity Dimensions: 6.27-inch diameter x 1.9-inch deep Compatible Accessories: LSPKBB-CW - White ceiling backbox System Compatibility: Compatible with supervised 25 VRMS or 70 VRMS speaker circuits used in fire alarm, voice evacuation, and mass notification systems.
