Silent Knight IFP-2100ECS (Intelligent Addressable FACP w/ Emergency Communication System, Red Cabinet)

The IFP-2100ECS is an intelligent addressable fire alarm control panel with an integrated Emergency Communication System in a red, surface-mount cabinet. One built-in SLC supports 159 IDP detectors and 159 IDP modules per loop (or 127 SD devices per loop) and system capacity can expand to 2100 points (IDP/SK) or 2032 points (SD). Eight Flexput circuits can be configured as NAC outputs or auxiliary power. Core ECS features include an onboard supervised microphone, fifteen recordable one-minute messages mapped to eight buttons, selectable 520 Hz tones, and support for 25 Vrms or 70.7 Vrms speaker circuits through external amplifiers. The panel networks multiple control units and supports up to 16 addressable amplifiers for a system total of 2000 W and up to 128 speaker circuits. Model Variants: IFP-2100ECS – Red Cabinet IFP-2100ECSB – Black Cabinet Key Specifications: Type: Intelligent addressable FACP with integrated ECS Device Capacity: Up to 2100 (IDP/SK) or 2032 (SD) addressable points per panel SLC Loops: 1 built-in loop supporting 159 IDP detectors and 159 IDP modules per loop, expandable via SLC expander NAC / Flexput Circuits: Eight configurable circuits, 3.0 A per circuit, 9.0 A total accessory load, power limited and supervised Audio / ECS: Fifteen 60 second messages, onboard microphone, dual channel and backup audio with ECS-DUAL50W, up to 16 amplifiers for 2000 W total, up to 128 speaker circuits, 25 Vrms or 70.7 Vrms speaker support Primary Power: 120 VAC 60 Hz, 2.5 A input Battery Support: Two 18 Ah batteries in cabinet, charger supports 7 to 55 Ah, larger batteries in RBB cabinet Networking: Supports multi-panel networking for shared control or independent operation Annunciation & Reporting: Supports RA-2000 annunciators and 5824 serial or parallel printer interface Compatible Modules & Accessories: ECS-50W, ECS-125W, ECS-DUAL50W, ECS-INT50W, ECS-50WBU – Amplifier options (50 W, 125 W, dual 50 W with backup, internal 50 W, external backup) ECS-CE4 – Four additional audio circuits ECS-RVM, ECS-SW24, ECS-VCM, ECS-RPU – Remote voice module, 24 switch expander, voice control module, remote paging unit (red) RA-2000, RA-2000GRAY – 4×40 LCD remote annunciator (red/gray) 5824 – Serial or parallel printer interface module 5815XL – SLC expander for SD addressable devices RPS-1000 – 6 A intelligent auxiliary power supply 5496 – 6 A NAC power expander 5880 – LED I/O module 5865-3 / 5865-4 – LED annunciators 5883 – Relay interface module RBB – Remote battery box accessory cabinet Compatible Detectors & Devices (IDP / System Sensor): IDP-PHOTO-W, IDP-PHOTO-IV – Photoelectric smoke detector IDP-PHOTO-T-IV – Photoelectric with fixed heat (135°F) IDP-HEAT-W, IDP-HEAT-IV – Fixed-temperature heat detector IDP-MONITOR, IDP-MINIMON – Monitor modules IDP-PULL-DA – Dual action pull station IDP-CONTROL – Supervised control module IDP-RELAY – Addressable relay module IDP-ISO – Line isolator module Also supports System Sensor SK-series equivalents, or SD-series devices (Hochiki protocol). Protocols cannot be mixed on the same system.
